Type

HEC800-

C5

HEC1000-

C5

HEC2000-

C5

HEC3000-

C5

HEC4000-

C5

HEC4000-

C5

HEC6000-

C5

Rated Current

800A

1000A

2000A

3000A

4000A

5000A

6000A

Linear Range

1.5 times of the maximum of measuring range

6500A

Output Voltage

4V 、 5V (output current 0-20mA or 4-20mA)

Accuracy

±1%

Offset Voltage

±20mV

Hysteresis Error

±10mV

Temperature Drift

0.05%/ ℃

Response Time

＜ 10μS di/dt=50A/μS

Power Supply

± 12V 、± 15V （± 5% ）

Current Consumption 18mA

Isolation 3KV AC 50Hz/min

Operating Temperature Range -10 ℃ ～ +80 ℃

Storage Temperature Range -25 ℃ ～ +85 ℃
