Type

HEC600-

B3

HEC800-

B3

HEC1000-

B3

HEC1200-

B3

HEC1500-

B3

HEC2000-

B3

HEC2500-

B3

Rated Current

600A

800A

1000A

1200A

1500A

2000A

2500A

Linear Range

1.5 times of the maximum of measuring range

2800A

Output Voltage

4V 、 5V

Accuracy

±1%

Offset Voltage

±20mV

Hysteresis Error

±10mV

Temperature Drift

0.05%/ ℃

Response Time

＜ 10μS di/dt=50A/μS

Power Supply

± 12V 、± 15V （± 5% ）

Current Consumption 18mA

Isolation 3KV AC 50Hz/min

Operating Temperature Range -10 ℃ ～ +80 ℃

Storage Temperature Range -25 ℃ ～ +85 ℃
